100Mbps 5 Port PoE Extender PoE Repeater 802.3af/at

Name: 100Mbps 5 Port PoE Extender PoE Repeater 802.3af/at
Price: 6.3 USD
Availability: InStock

Model:WXA-AT14FV

1 x 10/100M RJ45 PoE/PD

4x 10/100M RJ45 PoE/PSE

Waterproof Optional

DIN-Rail Installation

Original price was: $11.80.Current price is: $6.30.

Category: PoE Extender Tags: 100Mbps 30W PoE Din-rail

Provides 1*100Mbps IEEE802.3af/at(PoE) powered port input and 4*100Mbps IEEE802.3af/at(PoE) powered ports output. The whole power is 30W, and the average output power is 8W per port.

1*IEEE802.3af/at (PoE) powered port input
4*IEEE802.3af/at (PoE) powered port output
With network and POE relay extension role

Network Standard	IEEE 802.3、IEEE 802.3u、IEEE 802.3x
Port	410/100Mbps RJ45 power supply port 110/100Mbps RJ45 receiving port
POE Power	The whole power is 30W Output power of single port is 24W, average output power per port is 8W
POE Connection	POE input receiving wire core: 1/2+, 3/6-, 4/5+, 7/8- POE output power supply core: 1/2+, 3/6- 100M Transmission
Performance	Store and forward MAC address table 2k Switching capacity 10Gbps
Forwarding Rate	10BASE-T:14880PPS/port 100BASE-tx：148800pps/port 1000BASE-tx：1488000pps/port
Port Function	Power priority mechanism, fast and forward, MAC automatic learning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode
Environment	Operating Temperature：-10℃ – -55℃
Power	Input：DC44-57V，30W；Output：DC44-57V，24W
Weight &Size	55g 82mm×52mm×23mm
